Abart Pro Sonic Dual - drive enclosure - HUB - 2x NVMe M.2 SSD PCIe USB4 Thunderbolt 40 Gb/s HDMI USB-C 40 Gb/s USB-A 10 Gb/s

The Abart Pro Sonic Dual is an innovative enclosure for TWO M.2 NVMe PCIe SSDs with active cooling - a built-in fan controlled automatically or manually.

This rugged, aesthetically pleasing and well heat dissipating powered enclosure that holds up to two M.2 PCIe NVMe drives is compatible with all USB-C connector standards i.e., Thunderbolt™ 5, Thunderbolt™ 4, Thunderbolt™ 3, USB4, USB3.2, USB3.1.

High transfer rates of up to 40Gbps are also achieved on Apple computers with Silicon processors i.e. M1, M2, M3 and M4 series processors. The fan-enabled pockets are recommended for NVMe PCIe SSDs due to their active cooling and effective heat dissipation. The pocket is also equipped with HDMI 8K60Hz, USB-C 40 Gbps, USB-A 10 Gbps and Power Delivery 100W.

The Abart Pro Sonic Dual 40Gbps USB4 Thunderbolt 2x M.2 NVMe enclosure is a two-pocket RAID hub - software - where you can combine 2 NVMe SSDs into one fast and reliable portable drive!

Synchronize data at speeds of up to 40 Gbps and transfer large files in just seconds, significantly increasing productivity. The speed of the drives can reach 2800 Mbps in RAID 0 configuration, with each drive separately transferring data at about 1500 Mbps. The actual transfer speed depends on the drives used and the connected host.

The case features a 3-core Thunderbolt™ chipset with official Intel® certification. The chipset provides powerful performance and broad compatibility including Apple Macs with Intel/M1/M2/M3 and M4 processors. Each functional interface is controlled by an independent chip, ensuring fast transfer speeds and no latency. Even when multiple functions are used simultaneously, operation remains smooth. In addition, the device has been certified for Windows and macOS, meeting their technical and licensing requirements.

The Abart Pro Sonic Dual SSD enclosure is equipped with 2 M.2 PCIE NVMe SSD slots. Each SSD supports up to 8TB of capacity and up to 16TB of capacity in RAID 0 mode. The Abart Pro Sonic Dual is the ideal solution for expanding storage capacity and fast data transfer.

Abart Pro Sonic Dual enclosure designed specifically for M.2 M key and B&M Keys, 2230 /2242 /2260 /2280 NVMe SSD. It is not compatible with SATA M.2 NVMe SSDs.

Tool-free magnetic fasteners for easy installation. Compact and easy to carry. Robust aluminum construction for durability and maximum heat dissipation. Integrated temperature and status monitoring system.

Pocket - HUB - abart Pro Sonic Dual is compatible with multiple operating systems: Windows, macOS, Linux, Android, iPadOS. Full compatibility with Thunderbolt 5/4/3, USB4 interfaces. Compatible with many devices, including iPads and smartphones. Requires a 100W power adapter, which is included.

In addition to two ports for M.2 NVMe SSD drives, the Abart Pro Sonic Dual Pocket can also expand the device's interfaces with an additional HDMI 8K60Hz, USB-A 3.1 10 Gbps and USB-C, Thunderbolt 40 Gbps port, so you no longer have to worry about insufficient interfaces affecting the performance of your workstation.

Specifications:

• Code: ABP-Sonic-Dual
• EAN: 5904917097885
• Host connection interface: Thunderbolt, USB4 up to 40 Gbps
• Disk support: 2x M.2 NVMe SSD PCIe drive
• Disk format: 2230, 2242, 2260, 2280
• RAID support: yes, software-based
• Maximum capacity: up to 16TB in RAID-0, 8TB per M.2 channel
• HDMI connectivity: 2.0 up to 8K60Hz
• Thunderbolt/USB4 connector: 2x 40GB/s including one for host connection
• USB-A connector: 3.2 1x 10Gbps
• PnP: Yes
• Power Delivery: up to 100W
• Thunderbolt daisy-chain connection: yes
• Compatible with macOS, iPadOS, iOS, Windows, Linux
• Monitor support: 1x 8K60Hz or 2x 4K60Hz
• Included: enclosure (hub), Thunderbolt (USB4) 40 Gbps cable, 100W power supply, 2x ThermalPad for drives
